Video System
:
NTSC / PAL (auto switchable)
Video Input
:
8 channels (composite video signal 1 Vp-p 75Ω BNC)
Video Input
:
Main monitor output (composite video signal 1 Vp-p 75Ω BNC)
Audio Input / Output
:
4 audio inputs, 1 audio output (Mono)
Maximum Recording Rate (Frame)
:
704×480 pixels with 60 IPS / 704×576 pixels with 50 IPS
Maximum Recording Rate (Field)
:
704×240 pixels with 120 IPS / 704×288 pixels with 100 IPS
Maximum Recording Rate (CIF)
:
352×240 pixels with 240 IPS / 352×288 pixels with 200 IPS
Adjustable Recording Speed (Frame)
:
60, 30, 15, 7 IPS / 50, 25, 12, 6 IPS
Adjustable Recording Speed (Field)
:
120, 60, 30, 15 IPS / 100, 50, 25, 12 IPS
Adjustable Recording Speed (CIF)
:
240, 120, 60, 30 IPS / 200, 100, 50, 25 IPS
Image Quality Setting
:
Best, High, Normal and Basic
Hard Disk Storage
:
Accommodates 2 SATA HDDs (1 HDD capacity up to 1TB)
SATA Interface
:
Built-in
VGA Interface
:
Built-in (output resolution up to 1600 x 1200)
Quick Search
:
Time / Motion / Alarm search mode
Recording Mode
:
Manual / Timer / Motion / Alarm / Remote
Refresh Rate
:
240 IPS for NTSC / 200 IPS for PAL
Multiplex Operation
:
Live display / record (8 channels) / playback (simultaneously up to 4 channels)
/ backup / network operations
Remote Independent Operation
:
Fully remote independent operation
R.E.T.R. (Remote Event Trigger Recording)
:
YES
Motion Detection Area
:
16 × 12 grids per camera for all channels
Motion Detection Sensitivity
:
One parameter with three sensitivity levels (High / Normal / Low)
Pre-alarm Recording
:
YES (8 MB)
Backup Device
:
USB 2.0 flash drive / Network
USB Interface
:
Front panel * 1 / Back panel * 1
Ethernet
:
10/100 Base-T. Supports remote control and live view via Ethernet
Remote Independent Operation
:
Yes
Web Interface
:
Licensed software “Video Viewer” / Internet Explorer or Mozilla Firefox web browser
/ QuickTime player (5 users access simultaneously) *Operating System: Windows Vista
/ XP / 2000; Apple Mac
Network Protocol
:
TCP/IP, PPPOE, DHCP and DDNS
IR Remote Control
:
YES (IR receiver built-in)
Dwell Time (Sequential Channel Switch)
:
Programmable with adjustable dwell time (3 / 5 / 10 / 15 seconds)
Motion Detection Area
:
16 × 12 grids per channel
Alarm Input / Output
:
8 inputs, 1 output
Picture Zoom
:
2X digital zoom (LIVE & Playback)
Key Lock (Password Protection)
:
YES
Video Loss Detection
:
YES
Camera Title
:
Supports up to 6 letters
Video Adjustable
:
Hue / Saturation / Contrast / Brightness
Date Display Format
:
YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off
Power Source (±10%)
:
DC 19V
Power Consumption (±10%)
:
<64 W>
Operating Temperature
:
10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)**
:
430(W) x 65(H) x 338(D)
System Recovery
:
System auto recovery after power failure
Optional Peripherals
:
Keyboard controller
